Zoom lightbox

1. Copy to Webflow

   Add Geist and Geist Mono to your site's fonts (Site settings, Fonts, Google Fonts) before pasting: Webflow removes any font your site has not installed.
   Copy to Webflow

2. Add custom CSS

   To keep things simple, the code ships inside the Webflow embed. You can also copy it here and add it yourself to the page or site custom code. How to choose

   The look of the preview is the zoom-lightbox-* classes of the paste. The code is longer than one Webflow Embed holds, so the paste brings two: this stylesheet and the settings are the first, the script of the next step the second. The first Embed holds the look of the viewer, and reads five variables, --zoom-lightbox-ground (the sheet behind the picture), --zoom-lightbox-ink, --zoom-lightbox-accent, --zoom-lightbox-label-font and --zoom-lightbox-pad: set them on the group, or on anything above it, in a rule of your own. The caption takes the typeface of the group.

3. Add custom JS

   To keep things simple, the code ships inside the Webflow embed. You can also copy it here and add it yourself to the page or site custom code. How to choose

4. Use it on your own elements

   Custom attributes
   Select the element on the canvas and open the Settings panel. Under Custom attributes, add a pair: the name on the left, the value on the right.

   Custom attribute	What it does
   data-zoom-lightbox	Marks the group of pictures. It takes no value: leave the value field empty. Every picture inside it opens in the viewer, in the order of the page, one picture or forty, any shape. The settings below go on the same element.
   data-zoom-lightbox-caption	On a picture, with a few words as its value: the caption of that picture in the viewer, in place of its alt. Left empty, that picture has no caption. Without it the caption is the figcaption around the picture, or its alt. [ Optional ]
   data-zoom-lightbox-src	On a picture, with the address of a larger file as its value: what the viewer lays over the picture of the page once it has arrived. Without it the viewer takes the file a link around the picture leads to, or the largest candidate of its srcset, which is what a Webflow Image carries, or the picture of the page itself. [ Optional ]
   data-zoom-lightbox-item	On a few pictures of the group, with no value: only those open in the viewer and the others are left alone. Without it on any picture, every picture of the group opens. [ Optional ]
   data-zoom-lightbox-away	Written by the engine on the thumbnail whose picture is in the viewer, so its place stays empty; each picture that opens also carries data-zoom-lightbox-trigger, the group data-zoom-lightbox-ready, and the viewer data-zoom-lightbox-state (opening, open, dragging, closing) and data-zoom-lightbox-ui while its words are shown. Never written by hand; the stylesheet reads them, and so can a rule of yours. [ Optional ]

   Settings
   Every setting is a custom attribute too, added the same way and on the same element. An attribute always wins over the defaults written in the code.

   Attribute	Default	What it is
   data-zoom-lightbox-duration	0.95	The time the picture takes from its thumbnail to full size, in seconds. The way back, the change of picture and the words follow it.
   data-zoom-lightbox-arc	0.5	How much the trip bows away from the straight line, and how much the picture leans into it.
   data-zoom-lightbox-loop	on	Whether the last picture leads to the first. Options: on, Next on the last picture goes to the first and Prev on the first to the last; off, the two ends stop, and the button that leads nowhere is dimmed.
   data-zoom-lightbox-close	Close	The word of the button that closes the viewer. Options: any short word, in the language of the page: Fermer, Schliessen.
   data-zoom-lightbox-prev	Prev	The word of the button that goes to the picture before. Options: any short word, in the language of the page: Avant.
   data-zoom-lightbox-next	Next	The word of the button that goes to the picture after. Options: any short word, in the language of the page: Suivant.

Two files and their pictures (18), no build step. It runs in the browser only. Load it with a script tag in plain HTML, in a client-side script in Astro, never in the frontmatter. In React, call ZoomLightbox.mount(ref.current) in useEffect and destroy() in its cleanup.

1. Tune it, either way

   Per element with an attribute, or once for the whole site by editing DEFAULTS at the top of the file.

   Attribute	Default	What it is	Lower	Higher
   data-zoom-lightbox-duration	0.95	The time the picture takes from its thumbnail to full size, in seconds. The way back, the change of picture and the words follow it.	Quicker; under 0.6 the curve and the ground are hardly seen; 0 opens at once	Slower and more shown; over 1.4 the viewer feels late on the click
   data-zoom-lightbox-arc	0.5	How much the trip bows away from the straight line, and how much the picture leans into it.	Straighter; 0 is a straight line with no lean	A wider curve and more lean; 1 is the most
   data-zoom-lightbox-loop	on	Whether the last picture leads to the first. Options: on, Next on the last picture goes to the first and Prev on the first to the last; off, the two ends stop, and the button that leads nowhere is dimmed.
   data-zoom-lightbox-close	Close	The word of the button that closes the viewer. Options: any short word, in the language of the page: Fermer, Schliessen.
   data-zoom-lightbox-prev	Prev	The word of the button that goes to the picture before. Options: any short word, in the language of the page: Avant.
   data-zoom-lightbox-next	Next	The word of the button that goes to the picture after. Options: any short word, in the language of the page: Suivant.

2. Drive it from JavaScript

   When a button elsewhere opens the gallery, when the pictures change after load, or when the page follows which picture is shown.
   JavaScript Expand Copy

   const element = document.querySelector('[data-zoom-lightbox]');
   element.addEventListener('zoomlightbox:shown', (e) => {
     console.log(e.detail);
   });

   // Follow the picture in the viewer: an analytics call, an address to update.
   element.addEventListener('zoomlightbox:shown', (event) => {
     console.log(event.detail.index, event.detail.item);
   });

   const viewer = ZoomLightbox.mount(element);   // the group auto() mounted, or a new one
   viewer.open(2);   // the third picture leaves its thumbnail

   // Once a picture is shown: viewer.next(), viewer.prev(), viewer.go(5) and viewer.close().

   // When the gallery leaves the page:
   ZoomLightbox.destroy(element);   // removes the viewer, gives the markup back as it was

   Show all 17 lines

3. Fit it to your page

   The pictures

   • Mark the group, and that is all: data-zoom-lightbox on the block that holds the pictures. One picture or forty, upright, wide or square, in a grid, a row or a text: each img in the group opens, and Prev and Next follow the order of the page. With one picture the count and the two buttons are not shown.
   • A thumbnail may be cropped by the page: object-fit: cover, an object-position, an aspect ratio, a small radius. The picture leaves from exactly that window and opens to its whole shape on the way.
   • The caption is the alt of the picture. To say something else, put data-zoom-lightbox-caption="Your words" on the picture; leave the attribute empty for no caption. A figcaption in a figure around the picture is read before the alt.
   • A larger file, three ways. Wrap the picture in a link to it, <a href="https://example.com/large.jpg"><img src="https://example.com/small.jpg" alt=""></a>: without JavaScript the link still opens the file. Or give the picture a srcset: the viewer asks for the candidate that suits the whole screen, which is what a Webflow Image does by itself. Or name it, data-zoom-lightbox-src="https://example.com/large.jpg". In every case the viewer shows what the page already has, at once, and lays the large file over it when it is decoded: the trip never waits and nothing blinks.
   • A picture inside a link to a page is left alone: the link keeps leading to its page.
   • Several galleries on a page each work on their own, each with its own settings and colours.

   The keyboard, the mouse, the finger

   Tab reaches each thumbnail; Enter or Space opens it. In the viewer the focus is on Close and Tab goes round the three buttons without leaving. Left and Right change the picture, Home and End go to the first and the last, Escape closes, and the focus returns to the thumbnail of the picture that was open.

   A click on the picture goes to the next one; a click beside it closes. A drag across the picture, with the mouse or a finger, goes to the next or the one before. A drag up or down takes the picture off its ground, which shrinks around it; let go far enough or fast enough and it flies back to its thumbnail, let go early and it returns to the middle.

   The colours and the sizes

   Five custom properties, set at zero specificity on the group. Give them your own values on the group or on anything above it; the viewer, which is added at the end of the page, reads them from its group each time it opens, and takes the typeface of the group for the caption.

   • --zoom-lightbox-ground: the sheet behind the picture, warm black in the preview. A light ground works as well.
   • --zoom-lightbox-ink: the count, the caption and the three words.
   • --zoom-lightbox-accent: a word under the pointer, and the focus ring.
   • --zoom-lightbox-label-font: the typeface of the count and of the three words.
   • --zoom-lightbox-pad: the margin of the viewer, around the words and around the picture.

   From JavaScript

   • ZoomLightbox.mount(element, overrides) returns the instance of a group, mounting it if it was not: { element, settings, items(), index(), state(), open(which, options), close(options), go(which, options), next(), prev(), refresh(), destroy() }. open takes a number counted from 0 or a thumbnail element, and { instant: true } to skip the trip, or { hold: 0.5 } to stop it at that share of the way, for a still; close() goes on from there. ZoomLightbox.auto(root) mounts every marked group inside root, and runs once on its own; ZoomLightbox.destroy(element) gives the markup back.
   • Events, all bubbling from the group: zoomlightbox:ready, fired during the mount, so before any listener added after the script tag (read items() on the instance instead); zoomlightbox:open as the picture leaves its thumbnail; zoomlightbox:change as soon as another picture is asked for, with { index, previous, item }; zoomlightbox:shown once a picture is in place; zoomlightbox:close once it is back in its thumbnail.
   • Pictures added after the mount are taken in by refresh().
   • **Under prefers-reduced-motion: reduce** the viewer opens, changes and closes at once, with no trip and no wipe.
   • Without JavaScript the gallery is the page's own pictures, and a picture wrapped in a link opens its file.
   • The photographs and the words of the demo are the demo's: on a real page every picture and caption is the user's own, or asked for.

4. Avoid the pitfalls

   • The attribute goes on the group, not on each picture. A group marked twice, once inside the other, is two galleries.
   • **Give each picture its width and height attributes**, as for any image: a thumbnail that has not loaded yet, lazy and far down the page, then still opens in a frame of the right shape.
   • **The viewer is added at the end of body**, in a native dialog, so a rule of the page that styles every dialog or every button reaches it. Its own classes all start with zoom-lightbox-.
   • The stylesheet places the viewer. Without zoom-lightbox.css there is no ground and the pictures are not placed, and the engine says so in the console.
   • A thumbnail that moves under the pointer, scaled on hover for one, is read where it is at the click, so the picture leaves from the scaled window. Keep such a hover small.
   • In Webflow the code is two Embed blocks, pasted together at the foot of the section: the settings and the stylesheet in the first, the script in the second. Keep both, the first above the second.
   • In Webflow use plain Image elements in the group, not Webflow's own Lightbox element, which brings its own viewer. A Webflow Image carries a srcset, so the viewer asks for a large enough file by itself.
   • The page behind is held still by overflow: hidden on the html element, with a padding the width of the scrollbar so nothing jumps. A bar fixed to the right edge of the page is not inside that padding: give it the same room if a shift of a few pixels shows.
   • A caption is one or two lines. It sits at the foot of the screen, beside the two buttons; a long paragraph pushes the picture up.
   • In React or any framework that owns the DOM, mount in an effect and call destroy() in its cleanup; after the list of pictures changes, call refresh().

One click on Copy the AI prompt copies everything an assistant needs to build this effect: the complete code, the markup, the dependency, every setting and every pitfall.
