Pixel swap

1. Copy to Webflow

   Add Geist and Geist Mono to your site's fonts (Site settings, Fonts, Google Fonts) before pasting: Webflow removes any font your site has not installed.
   Copy to Webflow

2. Add custom CSS

   To keep things simple, the code ships inside the Webflow embed. You can also copy it here and add it yourself to the page or site custom code. How to choose

3. Add custom JS

   To keep things simple, the code ships inside the Webflow embed. You can also copy it here and add it yourself to the page or site custom code. How to choose

4. Use it on your own elements

   Custom attribute
   Select the element on the canvas and open the Settings panel. Under Custom attributes, add a pair: the name on the left, the value on the right.

   Custom attribute	What it does
   data-pixel-swap	Marks the element the effect plays on. It takes no value: leave the value field empty.

   Settings
   Every setting is a custom attribute too, added the same way and on the same element. An attribute always wins over the defaults written in the code.

   Attribute	Default	What it is
   data-accent	#ffab1a	Flash colour on a square that has just turned. Options: any CSS colour; taken out of this block, --pixel-swap-accent on the box then the page's --accent take over.
   data-cell	15	Side of one square the trail turns over, kept in px so the grain is the same on every screen.
   data-radius	74	Half width of the brush that opens the second image, any CSS unit.
   data-edge	0.42	How ragged the rim of that brush is, 0 to 1.
   data-hold	0.9	How long a square keeps showing the second image once the cursor has left it, in seconds.
   data-hold-jitter	0.55	Spread of that hold from one square to the next, 0 to 1.
   data-front	0.3	How long a square that has just turned keeps its accent flash, in seconds.
   data-front-intensity	0	Strength of that flash, 0 to 1.
   data-flat	1	How solid the lit squares are, 0 to 1.

Two files and their pictures (6), no build step. It runs in the browser only. Load it with a script tag in plain HTML, in a client-side script in Astro, never in the frontmatter. In React, call PixelSwap.mount(ref.current) in useEffect and destroy() in its cleanup.

1. Tune it, either way

   Per element with an attribute, or once for the whole site by editing DEFAULTS at the top of the file.

   Attribute	Default	What it is	Lower	Higher
   data-accent	#ffab1a	Flash colour on a square that has just turned. Options: any CSS colour; taken out of this block, --pixel-swap-accent on the box then the page's --accent take over.
   data-cell	15	Side of one square the trail turns over, kept in px so the grain is the same on every screen.	A fine grain, many more squares to redraw	Chunky blocks, cheaper to draw
   data-radius	74	Half width of the brush that opens the second image, any CSS unit.	A thin wake right under the cursor	A wide patch that opens most of the box at once
   data-edge	0.42	How ragged the rim of that brush is, 0 to 1.	At 0 a clean disc, which reads as a mask rather than as pixels	A broken rim, squares scattered ahead of the stroke
   data-hold	0.9	How long a square keeps showing the second image once the cursor has left it, in seconds.	The trail closes right behind the cursor	The second image stays open across the whole box
   data-hold-jitter	0.55	Spread of that hold from one square to the next, 0 to 1.	At 0 the trail shuts in one block, which reads as a glitch	A ragged close, squares dropping out one by one
   data-front	0.3	How long a square that has just turned keeps its accent flash, in seconds.	Barely a spark on the rim	The whole opened patch stays tinted
   data-front-intensity	0	Strength of that flash, 0 to 1.	At 0, the default, no flash: the second image shows at once. Just above, the accent is only a hint	Past 0.5 a whole disc lights at once and the accent repaints the picture
   data-flat	1	How solid the lit squares are, 0 to 1.	A light that fades behind the front	At 1 real squares of flat colour, which then turn into the picture

2. Drive it from JavaScript

   When the two sources are not <img> elements, a canvas for instance, or when you want to react to what the component does.
   JavaScript Expand Copy

   const element = document.querySelector('[data-pixel-swap]');
   element.addEventListener('pixelswap:open', (e) => {
     console.log(e.detail);
   });

   const swap = PixelSwap.mount(element);   // the box auto() mounted, or a new one

   // Two sources that are not <img> elements: here, two canvases painted in code.
   function paint(color) {
     const canvas = document.createElement('canvas');
     canvas.width = canvas.height = 600;
     const context = canvas.getContext('2d');
     context.fillStyle = color;
     context.fillRect(0, 0, 600, 600);
     return canvas;
   }
   swap.setSources([paint('#f4ece0'), paint('#15100c')]);

   // When the box leaves the page:
   swap.destroy();   // removes the canvas and the listeners

   Show all 20 lines

3. Fit it to your page

   • One setting for every box of the page, without opening the file: declare window.PixelSwapSettings = { hold: 0.8 } in a script placed before pixel-swap.js. The three levels, least specific first, are DEFAULTS, then that object, then a data-* attribute on the box itself, so one box can still differ from the page-wide setting.
   • The size and the ratio of the box are not a setting. The box is a real element of the page, so it is styled like any other element: a class in the Webflow Designer, a rule in a stylesheet. The engine measures it, fills it, and follows it when the window changes.
   • Minimal structure: one box, two <img> inside it. The first is shown, the second is taken out of the layout by the stylesheet and revealed square by square. In Webflow they are two Image elements the user swaps in the Navigator. The script adds a <canvas> of its own (class pixel-swap-canvas, position: absolute; inset: 0; pointer-events: none, written inline as well as in the stylesheet, so the canvas is out of the flow before the stylesheet arrives), with no z-index, so anything the page lays over the box still paints on top.
   • The effect works on one image box, and nothing else. The canvas fills that box edge to edge, and the squares are that box. There is nothing to frame and nothing to wrap the picture in. If you see squares turning in a margin around your subject, that margin is part of your image, not part of the component.
   • The squares never look at what they are showing. A square only knows which of the two sources it is drawing, so a photograph, a poster, a product shot and a screenshot all behave identically. Different box ratios in the same page cost nothing.
   • What appears in one source and not the other is free. A window lit in one picture and dark in the other, a poster whose ground changes: nothing has to line up except the framing.
   • Both sources must share their framing. The effect swaps squares at the same coordinates, so a different crop between the two reads as a glitch rather than as a swap. Shoot or export them on the same ground. Sizes do not have to match: every source is redrawn once into a canvas the size of the box, centred and cropped the way object-fit: cover would, which is also what the visible <img> is told to do.
   • Sources that are not images: PixelSwap.mount(el, { sources: [a, b] }) takes canvases, which is how a page hands over pictures it paints itself. On a box already mounted, the same call, or setSources([a, b]), hands them over. Sources handed in win over anything found in the markup.
   • **From JavaScript, beyond mount, setSources and destroy**: the api also carries element, settings, resize(), render() to draw one frame by hand, and isOpen(). The box emits pixelswap:close when the last square has turned back, as well as pixelswap:open when the first one turns, with { cells, count } as event.detail.
   • freeze() holds the box as a still picture: the squares that turned keep the second image instead of closing on their own clock, the loop stops as soon as the last flash is out, and nothing redraws until something asks. unfreeze() hands the squares back to their clock and they close at once. PixelSwap.freeze(el) and PixelSwap.unfreeze(el) do the same from the element. It exists so a still image of the effect can be taken, a thumbnail that has to show the swap standing still: a page never calls it.
   • Touch: there is no hover to follow, so a tap turns the whole box over and a second tap brings it back. A trail that needed a pointer path would show nothing at all on a phone.
   • **prefers-reduced-motion**: the picture still swaps, it just stops crawling. Hovering the box turns the whole of it over, leaving brings it back.
   • The words of the markup are the preview's, and they ship as they are: pasted, the page reads the way the preview did. Put the user's own content in their place whenever they want, in the page's language.
   • The staging script at the end of the markup ships with the words: it blinks the caret, lights the frame of an open box, names the stock underneath in its caption and writes the status line. It reads data-under on a box, data-name and data-code in its caption, data-readout on the status line and data-caret on the caret, and listens to pixelswap:open and pixelswap:close only. The swap needs none of it. The frame and the lit code are drawn by the Embed on data-pixel-swap-box and data-pixel-swap-code, never on a class, which Webflow renames when it is pasted twice on one site (AB-116).
   • On Webflow, add the fonts first. Add Geist and Geist Mono to your site's fonts (Site settings, Fonts, Google Fonts) before pasting: the paste names them, and the Designer drops a font the site does not have.

4. Avoid the pitfalls

   • Without the stylesheet, the second picture shows. The engine keeps its own canvas out of the flow, but taking the second <img> out of the layout and cropping the first are the job of pixel-swap.css: load the script alone and both pictures stack in the box at their natural size. Link the stylesheet, or style the two images yourself.
   • The image addresses of the markup are relative, images/…, so they point at the images/ folder next to the page holding the markup. Moved into another page or a framework route, they have to be pointed at wherever your pictures are served from.
   • **Settings handed to mount() after the page loaded are dropped.** auto() mounts on DOM ready, and mount() on a box that already carries a swap returns the existing one, taking only its sources. A page-wide block therefore goes in window.PixelSwapSettings, which auto() reads itself; handed to a later mount() call it is silently dropped, and the settings block ends up looking decorative.
   • An image that never loads leaves the box with one source, and then nothing happens: no error, no warning, nothing to reveal. The engine gives up on any single image after 8 s, so a dead URL shows as a box that never swaps. Check both addresses first.
   • **The accent goes to a canvas, which cannot parse color-mix().** A colour written that way, in data-accent, in --pixel-swap-accent or in the page's --accent, paints black without a word. Give it a plain colour, a hex or an rgb().
   • There is no flash by default. frontIntensity is 0, so accent, front and flat do nothing until it is raised. At 1 with flat 1, the squares that open are plain accent and ease into the picture over front. For a light that only hints at the accent, lower flat to 0 and set frontIntensity to about 0.4. No still image will tell you whether you got it right: this one has to be judged with a mouse in hand.
   • Never read a pixel back from the canvas. A picture served from the Webflow CDN, or from any other origin without CORS, taints the canvas and makes getImageData throw. A test that wants to know whether a trail opened counts pixelswap:open instead.
   • A caption cannot follow the coverage. With a trail, the share of the picture showing through never settles, so a label driven by it flickers between two names. The demo's caption follows pixelswap:open and pixelswap:close instead.

One click on Copy the AI prompt copies everything an assistant needs to build this effect: the complete code, the markup, the dependency, every setting and every pitfall.
