Infinite grid

1. Copy to Webflow

   Add Geist and Geist Mono to your site's fonts (Site settings, Fonts, Google Fonts) before pasting: Webflow removes any font your site has not installed.
   Copy to Webflow

2. Add custom CSS

   To keep things simple, the code ships inside the Webflow embed. You can also copy it here and add it yourself to the page or site custom code. How to choose

   Give the wall a height: once mounted the tiles are placed by the script and no longer push the box open. The size of a tile is not a class here but the width and height settings, which the script hands to the stylesheet. And leave the transform of a tile to the engine, which writes it every frame.

3. Add custom JS

   To keep things simple, the code ships inside the Webflow embed. You can also copy it here and add it yourself to the page or site custom code. How to choose

4. Use it on your own elements

   Custom attributes
   Select the element on the canvas and open the Settings panel. Under Custom attributes, add a pair: the name on the left, the value on the right.

   Custom attribute	What it does
   data-infinite-grid	Marks the box that holds the tiles. It takes no value: leave the value field empty. That box is the wall: what the hand drags, what the lens is measured on, what the effect is mounted on and what carries the settings. It takes its height from the page. Without it on any box of the page, the embed marks the parent of every tile it finds (data-infinite-grid-tile).
   data-infinite-grid-tile	Marks one tile, a direct child of the wall. It takes no value. A tile can be a link: a plain click still opens it, a drag never does. Without it on any tile, the wall takes its own children as the tiles. [ Optional ]
   data-infinite-grid-state	Written by the engine on the wall once mounted: ready. Never written by hand; the stylesheet reads it to clip the wall, keep the gesture, take the tiles out of the flow and lay the shadow of the lens. [ Optional ]
   data-infinite-grid-dragging	Written by the engine on the wall while a drag runs. Never written by hand; the stylesheet reads it for the closed hand. [ Optional ]
   data-infinite-grid-clone	Written by the engine on the copies of the tiles it adds to fill the wall, each one hidden from screen readers and out of the Tab order. Never written by hand. [ Optional ]

   Settings
   Every setting is a custom attribute too, added the same way and on the same element. An attribute always wins over the defaults written in the code.

   Attribute	Default	What it is
   data-infinite-grid-tint	#0e0b09	Colour the wall falls into towards its corners, the ground of the page in the preview. Options: any CSS colour, best the colour behind the wall; taken out of this block, --infinite-grid-tint on the wall takes over.
   data-infinite-grid-shade	0.6	Strength of that shadow in the corners of the box, 0 to 1.
   data-infinite-grid-bulge	0.42	Curve of the lens, 0 to 0.8: how much the tiles shrink and lean away towards the edges.
   data-infinite-grid-swell	0.14	Bulge added while the wall runs fast, 0 to 0.3, gone again as it slows.
   data-infinite-grid-width	clamp(170px, 21vw, 420px)	Width of a tile, any CSS unit, as drawn in the middle of the box.
   data-infinite-grid-height	clamp(124px, 15.3vw, 306px)	Height of a tile, any CSS unit, as drawn in the middle of the box.
   data-infinite-grid-gap	clamp(12px, 1.7vw, 32px)	Space between two tiles, on both axes, any CSS unit.
   data-infinite-grid-stagger	0.5	How far every other column sits lower, as a share of one cell, 0 to 1.
   data-infinite-grid-friction	0.05	Share of its speed a thrown wall loses on each frame, 0 to 1.
   data-infinite-grid-drift	22	Speed of the wall when nobody touches it, in pixels per second.
   data-infinite-grid-angle	24	Direction of that drift, in degrees: at 0 the tiles run to the left, at 90 upwards. Options: any angle; 180 runs to the right, 270 downwards.
   data-infinite-grid-wheel	1	Whether the wheel and the trackpad move the wall, 0 or 1.
   data-infinite-grid-lift	1.04	Scale of the tile right under the pointer.

Two files and their pictures (12), no build step. It runs in the browser only. Load it with a script tag in plain HTML, in a client-side script in Astro, never in the frontmatter. In React, call InfiniteGrid.mount(ref.current) in useEffect and destroy() in its cleanup.

1. Tune it, either way

   Per element with an attribute, or once for the whole site by editing DEFAULTS at the top of the file.

   Attribute	Default	What it is	Lower	Higher
   data-infinite-grid-tint	#0e0b09	Colour the wall falls into towards its corners, the ground of the page in the preview. Options: any CSS colour, best the colour behind the wall; taken out of this block, --infinite-grid-tint on the wall takes over.
   data-infinite-grid-shade	0.6	Strength of that shadow in the corners of the box, 0 to 1.	At 0 no shadow, the tiles keep their light to the edge	At 1 the corners are the tint itself and the wall reads as a deep bowl
   data-infinite-grid-bulge	0.42	Curve of the lens, 0 to 0.8: how much the tiles shrink and lean away towards the edges.	At 0 a flat wall, a plain endless grid	Past 0.6 a strong fisheye, many small tiles round the edges and more nodes on the page
   data-infinite-grid-swell	0.14	Bulge added while the wall runs fast, 0 to 0.3, gone again as it slows.	At 0 the lens never moves	A wall that visibly balloons on every throw
   data-infinite-grid-width	clamp(170px, 21vw, 420px)	Width of a tile, any CSS unit, as drawn in the middle of the box.	Small tiles, many on screen, more nodes on the page	A few large tiles, each one read on its own
   data-infinite-grid-height	clamp(124px, 15.3vw, 306px)	Height of a tile, any CSS unit, as drawn in the middle of the box.	Wide landscape tiles	Tall portrait tiles
   data-infinite-grid-gap	clamp(12px, 1.7vw, 32px)	Space between two tiles, on both axes, any CSS unit.	At 0 the tiles touch and the wall is one surface	A loose wall with a lot of ground between the tiles
   data-infinite-grid-stagger	0.5	How far every other column sits lower, as a share of one cell, 0 to 1.	At 0 a plain grid, the rows straight	At 0.5 a brick layout, each column half a tile lower than the last
   data-infinite-grid-friction	0.05	Share of its speed a thrown wall loses on each frame, 0 to 1.	A wall that glides a long way before it settles	A wall that settles almost where the hand left it
   data-infinite-grid-drift	22	Speed of the wall when nobody touches it, in pixels per second.	At 0 the wall stands still at rest and its clock sleeps	Past 60 the tiles are hard to read and to click as they pass
   data-infinite-grid-angle	24	Direction of that drift, in degrees: at 0 the tiles run to the left, at 90 upwards. Options: any angle; 180 runs to the right, 270 downwards.
   data-infinite-grid-wheel	1	Whether the wheel and the trackpad move the wall, 0 or 1.	At 0 the wheel scrolls the page as usual, over the wall too	At 1 the wall keeps the wheel, and the page does not scroll while the pointer is on it
   data-infinite-grid-lift	1.04	Scale of the tile right under the pointer.	At 1 no lift; under 1 the tile sinks instead	Past 1.1 the lifted tile covers its gap and touches its neighbours

2. Drive it from JavaScript

   When a button has to bring a tile to the middle, when the tiles change after load, or when the page reacts to a click on a tile that is not a link.
   JavaScript Expand Copy

   const element = document.querySelector('[data-infinite-grid]');
   element.addEventListener('infinitegrid:rest', (e) => {
     console.log(e.detail);
   });

   const wall = InfiniteGrid.mount(element);   // the box auto() mounted, or a new one
   wall.select(4);       // throws the wall to rest on the fifth tile
   wall.moveBy(1, 0);    // one tile to the right, as the arrow key does

   element.addEventListener('infinitegrid:click', (e) => {
     console.log(e.detail.index);   // the tile of the markup that was clicked
   });

   // When the wall leaves the page, or before its tiles change:
   InfiniteGrid.destroy(element);   // removes the copies and gives back the markup as it was

   Show all 15 lines

3. Fit it to your page

   • Structure: a box marked data-infinite-grid, and inside it the tiles, its direct children, each marked data-infinite-grid-tile. In the reference markup a tile is a link holding a picture and a caption line. Anything can go in a tile: a picture alone, a card with a title, a price, a tag. Twelve tiles is a good number; one is enough for the engine.
   • The wall takes its height from the page. Mounted, the tiles are placed by the script and no longer push the box open, so the box needs a height of its own: a full screen, a share of it, a fixed band. Whatever its shape, the wall fills it: the lens is measured on the diagonal of the box.
   • Tiles without the mark: a box with no marked tile takes its own children as the tiles, scripts and styles left out.
   • One setting for every wall of the page, without opening the file: declare window.InfiniteGridSettings = { bulge: 0.6 } in a script placed before infinite-grid.js. The three levels, least specific first, are DEFAULTS, then that object, then a data-infinite-grid-* attribute on the wall itself (data-infinite-grid-bulge="0.6"), so one wall can still differ from the page-wide setting.
   • The size of a tile is a setting here, not a class. The wall is laid out by the script, cell by cell, so the script has to know the cell: width, height and gap are read in pixels and handed to the stylesheet, which sizes every tile and every copy alike. That size is the one of a tile in the middle of the box; the lens draws the others smaller. What is inside a tile stays the page's own.
   • A click is still a click. A press that travels less than six pixels opens the tile's link, on a wall that drifts too. A drag never opens one, and a press on a wall thrown and still running stops it without opening the tile under it. For tiles that are not links, the wall emits infinitegrid:click with the tile of the markup that was clicked, whether the click landed on it or on one of its copies.
   • What the script writes. On the wall: data-infinite-grid-state="ready" once mounted, data-infinite-grid-dragging while a drag runs, tabindex="0" and role="group" when the markup gave none, and four custom properties, --infinite-grid-width, --infinite-grid-height, --infinite-grid-tint and --infinite-grid-shade. On each tile: a transform, a matrix3d. The copies carry data-infinite-grid-clone.
   • **From JavaScript, beyond mount, auto and destroy**: the api carries element, settings, tiles (the tiles of the markup), position() and speed() as { x, y }, phase() (rest, drift, hold, drag or glide), lens() (the bulge of the moment, swell included), nodes(), moveBy(columns, rows), select(index) which throws the wall so that tile comes to rest in the middle, and refresh(). The wall emits infinitegrid:start { element, x, y } when a drag begins, infinitegrid:rest { element, x, y, column, row, index, tile } each time a throw, a wheel or an aimed move has run out, and infinitegrid:click { element, index, tile, node, original } on a real click of a tile. All three bubble.
   • **destroy() leaves the wall as it was**: the copies removed, the listeners and the watches gone, the states, the custom properties and every transform taken off.
   • Keyboard: the wall takes the focus, and the arrow keys move it by one tile in their direction. Tab then reaches each tile of the markup in its order, and a tile that takes the focus is brought to the middle of the box, where the drift waits for as long as it keeps the focus. The copies never take the focus and are hidden from a screen reader, which reads each tile once. Give the wall an aria-label.
   • Touch: a finger drags and throws the wall on both axes, and a tap opens a tile. There is no pointer to lift a tile, so nothing lifts.
   • **prefers-reduced-motion**: the wall keeps its bulge, which is a layout and not a motion, follows the hand and stops where it is let go. Nothing drifts, swells, glides or lifts; the arrows, Tab and select() put the wall in place at once.
   • Out of the viewport the wall stops. Its clock sleeps while the box is off screen and starts again when it comes back, so a drifting wall far down a page costs nothing.
   • The words of the markup are the preview's, and they ship as they are. Put the user's own tiles in their place whenever they want.
   • On Webflow, add the fonts first. Add Geist and Geist Mono to your site's fonts (Site settings, Fonts, Google Fonts) before pasting: the paste names them, and the Designer drops a font the site does not have.

4. Avoid the pitfalls

   • A wall with no height shows nothing. The script says so once in the console. A percentage height needs a parent that has one.
   • Without the stylesheet the tiles are not placed. Taking them out of the flow, sizing them and anchoring the matrix on their top left corner is the job of infinite-grid.css; the script only writes transforms and custom properties.
   • A finger on the wall never scrolls the page. The wall keeps both axes of a swipe (touch-action: none), or a drag would fight the page scroll. On a phone, a wall as tall as the screen leaves nothing to scroll the page with: keep it shorter than the screen, or make it the whole page as the preview does.
   • **wheel at 1 keeps the wheel too.** While the pointer is on the wall the page does not scroll. Set data-infinite-grid-wheel="0" on a wall that sits in the middle of a long page.
   • The image addresses of snippet.html are relative, images/…, so they point at the images/ folder next to the page holding the markup, which is where the zip puts them. Moved into another page or a framework route, they have to be pointed at wherever your pictures are served from.
   • **Settings handed to mount() after the page loaded are dropped.** auto() mounts on DOM ready, and mount() on a wall that already carries the effect returns the existing one. A page-wide block goes in window.InfiniteGridSettings, which auto() reads itself.
   • The copies are clones of the markup. A listener added to a tile with addEventListener is not on its copies: listen on the wall for infinitegrid:click, or for click and read event.target.closest('[data-infinite-grid-tile]'). An id inside a tile is taken off its copies.
   • Do not put a transform, a transition or a transform-origin on a tile. The script writes the tile's matrix every frame, from its top left corner; a transition on it turns the drag into rubber. Style what is inside the tile.
   • The edges of a tile stay straight. Each tile is a flat rectangle laid on four points of the lens: the curve is read across the tiles, not along the side of one. Tiles wider than a third of the box start to show it; keep them smaller, or lower bulge.
   • Text in a tile is drawn through the matrix. Away from the middle it is as sharp as a rotated layer is, which is fine for a caption and wrong for a paragraph. Keep the words of a tile short.
   • **shade darkens the gaps too.** It is one layer over the whole wall, in the tint: on a ground of another colour, set tint to that colour, or the corners turn to mud.
   • **A strong bulge costs nodes.** The lens pulls more of the wall into the box, 1 / sqrt(1 - bulge) times further at the corners: about 1.3 times at the default, 2.2 times at 0.8, where the page holds near twice the nodes.
   • Tiles added or removed after mount are not seen. Destroy and mount again; refresh() only reads the sizes again.

One click on Copy the AI prompt copies everything an assistant needs to build this effect: the complete code, the markup, the dependency, every setting and every pitfall.
