Dot repel

1. Copy to Webflow

   Add Geist and Geist Mono to your site's fonts (Site settings, Fonts, Google Fonts) before pasting: Webflow removes any font your site has not installed.
   Copy to Webflow

2. Add custom CSS

   To keep things simple, the code ships inside the Webflow embed. You can also copy it here and add it yourself to the page or site custom code. How to choose

3. Add custom JS

   To keep things simple, the code ships inside the Webflow embed. You can also copy it here and add it yourself to the page or site custom code. How to choose

4. Tune it

   Custom attributes
   Select the section on the canvas and open the Settings panel. Under Custom attributes, add a pair: the name on the left, the value on the right.

   Custom attribute	What it does
   data-dot-repel	Marks the section the field lies behind. It takes no value: leave the value field empty. That section is what the canvas is laid under, what catches the pointer and what carries the settings, so it needs a height of its own. Without it on any section of the page, the embed marks the section it was pasted into.
   data-dot-repel-state	Written by the engine on the section: live while dots move, idle at rest, still under reduced motion, held for a frozen field. Never written by hand. [ Optional ]

   Settings
   Every setting is a custom attribute too, added the same way and on the same section. An attribute always wins over the defaults written in the code.

   Attribute	Default	What it is
   data-dot-repel-color	#15100c	Colour of the dots. Options: any CSS colour; taken out of this block, --dot-repel-color on the section takes over, then the ink #15100c.
   data-dot-repel-rest	0.12	Opacity of a dot at rest, 0 to 1.
   data-dot-repel-peak	0.34	Opacity of a dot pushed the farthest, the ones piled on the rim of the hole, 0 to 1; never under rest.
   data-dot-repel-spacing	16	Distance between two dots of the grid, in px.
   data-dot-repel-dot	1.2	Radius of a dot at rest, in px; kept under half the spacing.
   data-dot-repel-reach	clamp(120px, 12vw, 180px)	Radius of the area the pointer parts, any CSS unit.
   data-dot-repel-grow	1.35	Radius of a dot pushed the farthest, in times dot.
   data-dot-repel-push	0.28	How far the nearest dots are pushed, in times reach, 0 to 0.5.
   data-dot-repel-life	0.9	Time a dot takes to spring back once the pointer moves on, in seconds.

Two files, no build step. It runs in the browser only. Load it with a script tag in plain HTML, in a client-side script in Astro, never in the frontmatter. In React, call DotRepel.mount(ref.current) in useEffect and destroy() in its cleanup.

1. Tune it, either way

   Per element with an attribute, or once for the whole site by editing DEFAULTS at the top of the file.

   Attribute	Default	What it is	Lower	Higher
   data-dot-repel-color	#15100c	Colour of the dots. Options: any CSS colour; taken out of this block, --dot-repel-color on the section takes over, then the ink #15100c.
   data-dot-repel-rest	0.12	Opacity of a dot at rest, 0 to 1.	A screen you barely see until the pointer parts it	A plain dot grid that competes with the words
   data-dot-repel-peak	0.34	Opacity of a dot pushed the farthest, the ones piled on the rim of the hole, 0 to 1; never under rest.	The rim barely darker than the screen	A dark ring around the pointer
   data-dot-repel-spacing	16	Distance between two dots of the grid, in px.	A fine screen, more dots to redraw around the pointer	A coarse grid, the dots read one by one
   data-dot-repel-dot	1.2	Radius of a dot at rest, in px; kept under half the spacing.	Pin pricks	Heavy dots, a darker screen
   data-dot-repel-reach	clamp(120px, 12vw, 180px)	Radius of the area the pointer parts, any CSS unit.	A small hole, only the dots right under the pointer move	A wide parting, the whole middle of the hero shifts
   data-dot-repel-grow	1.35	Radius of a dot pushed the farthest, in times dot.	The rim keeps the size of the screen	Swollen dots on the rim
   data-dot-repel-push	0.28	How far the nearest dots are pushed, in times reach, 0 to 0.5.	A slight shift of the screen	A wide empty hole, the dots crowded on its edge
   data-dot-repel-life	0.9	Time a dot takes to spring back once the pointer moves on, in seconds.	A quick, tight return	A slow return that sways longer

2. Drive it from JavaScript

   When the section arrives after load, when a tap has to be played from code, or when the section changes size without the window doing so.
   JavaScript Copy

   const element = document.querySelector('[data-dot-repel]');

   const field = DotRepel.mount(element);   // the section auto() mounted, or a new one
   field.ripple(240, 180);   // a ripple from that point of the section
   field.resize();           // after the section changed size on its own

   // When the section leaves the page:
   field.destroy();   // removes the canvas and the listeners

3. Fit it to your page

   • One section, one attribute. Put data-dot-repel on the section the field lies behind. The script adds a <canvas> of its own as the first child (class dot-repel-layer, position: absolute; inset: 0; z-index: -1; pointer-events: none, written inline as well as in the stylesheet, so the canvas is out of the flow before the stylesheet arrives). It switches a static section to position: relative, and gives the section a stacking context of its own with isolation: isolate, so the canvas sits over the section's background and under every word and link. It never takes a click.
   • The section needs a background of its own, or none. The dots are drawn over the section's background colour; the page shows through where the section has none.
   • The sensitive area is the section, not the window: coordinates are relative to its getBoundingClientRect(). An empty section is 0px tall and shows no dot; give it content or a height.
   • One setting for every field of the page, without opening the file: declare window.DotRepelSettings = { spacing: 12 } in a script placed before dot-repel.js. The three levels, least specific first, are DEFAULTS, then that object, then a data-dot-repel-* attribute on the section itself (data-dot-repel-reach="200px"), so one section can still differ from the page-wide setting. The colour has one more level: without a color anywhere, the section's --dot-repel-color is read.
   • Touch: a finger drag parts the field too, through touch events, once the finger has travelled 10px, and the page still scrolls under it. A short tap that barely moves leaves a ripple: a ring that runs out from the point and pushes the dots it crosses, then lets them spring back.
   • **prefers-reduced-motion**: the screen of dots stays, still, and answers neither the pointer nor a tap. The engine listens to the setting and stops or starts with it.
   • Cost at rest is nothing: the loop only runs while a dot is moving. It sleeps once the field has settled, the pointer resting on it included, and stops in a hidden tab. The section carries data-dot-repel-state: live while the loop runs, idle at rest, still under reduced motion, held for a frozen field.
   • A resize rebuilds the grid: the window, or the section alone through a ResizeObserver. The field goes back to rest and reach is read again, so a vw or a clamp() follows the width.
   • From JavaScript: DotRepel.mount(el, overrides) returns the instance, which carries element, settings (the values it resolved, reach in px), resize(), ripple(x, y) (the ripple of a tap at a point of the section), clear(), frames() and isRunning() (rendered frames since mount, and whether the loop runs, for a test that the loop sleeps), and destroy(). destroy() takes away the canvas, every listener, the size watch and the loop, and gives the section's style attribute back as it was, so the markup is as it was and mounting again starts clean. DotRepel.destroy(el) does the same from the element. In React, mount in useEffect and destroy in its cleanup; the double run of StrictMode then leaves one field, not two.
   • freeze() holds the field as a still picture: the pointer leaving no longer closes the hole, the dots settle where the last move pushed them and the loop stops, so a held field costs nothing. unfreeze() lets the hole close again. DotRepel.freeze(el) and DotRepel.unfreeze(el) do the same from the element. It exists so a still image of the effect can be taken, a thumbnail that has to show the field parted at rest: a page that only wants the field never calls it.
   • The words of the markup are the preview's, and they ship as they are: pasted, the page reads the way the preview did. Put the user's own content in their place whenever they want, in the page's language.
   • On Webflow, add the fonts first. Add Geist and Geist Mono to your site's fonts (Site settings, Fonts, Google Fonts) before pasting: the paste names them, and the Designer drops a font the site does not have.

4. Avoid the pitfalls

   • **Settings handed to mount() after the page loaded are dropped.** auto() mounts on DOM ready, and mount() on a section that already carries a field returns the existing one untouched. A page-wide block therefore goes in window.DotRepelSettings, which auto() reads itself.
   • A child with a background of its own hides the dots under it. The canvas is under the content: a card, a band or an image inside the section covers the screen where it stands, which is usually what is wanted.
   • **A section with a z-index already has its stacking context**, so the script leaves isolation alone there. The canvas still sits under the content and over the background, since z-index: -1 is read inside the section's own context.
   • **Mouse and pen only for pointermove.** A touch pointer is ignored there on purpose, touch going through touch events; a page that fakes pointer events for a test has to give them pointerType: 'mouse'.

One click on Copy the AI prompt copies everything an assistant needs to build this effect: the complete code, the markup, the dependency, every setting and every pitfall.
