Pill nav

1. Copy to Webflow

   Add Geist and Geist Mono to your site's fonts (Site settings, Fonts, Google Fonts) before pasting: Webflow removes any font your site has not installed.
   Copy to Webflow

2. Add custom CSS

   To keep things simple, the code ships inside the Webflow embed. You can also copy it here and add it yourself to the page or site custom code. How to choose

   The pill is laid over the links and the text it covers is a copy drawn over the pill, so the box that holds the links must not clip (overflow: hidden) when the pill reaches past its edge, and its last link is no longer its :last-child.

3. Add custom JS

   To keep things simple, the code ships inside the Webflow embed. You can also copy it here and add it yourself to the page or site custom code. How to choose

4. Use it on your own elements

   Custom attributes
   Select the element on the canvas and open the Settings panel. Under Custom attributes, add a pair: the name on the left, the value on the right.

   Custom attribute	What it does
   data-pill-nav	Marks the box that holds the links. It takes no value: leave the value field empty. That box is what the pill travels in, what the effect is mounted on and what carries the settings. Without it on any box of the page, the embed marks the parent of the first link it finds next to itself, and says so in the console when there is none.
   data-pill-nav-link	Marks one link the pill can sit on, inside that box. It takes no value. Without it on any link, every link, button and tab of the box is taken. [ Optional ]
   aria-current="page"	Marks the current link, the one the pill rests on and comes back to. Webflow writes it by itself on a link to the page being shown. Without it on any link the pill is hidden at rest and shows under the pointer; a click then moves it to the clicked link. [ Optional ]
   data-pill-nav-state	Written by the engine on the box: live while the pill travels, idle at rest, empty when no link is current and none is under the pointer. Never written by hand. [ Optional ]

   Settings
   Every setting is a custom attribute too, added the same way and on the same element. An attribute always wins over the defaults written in the code.

   Attribute	Default	What it is
   data-pill-nav-color	#ffab1a	Colour of the pill, the amber #ffab1a by default. Options: any CSS colour; taken out of this block, --pill-nav-color on the bar takes over.
   data-pill-nav-ink	#15100c	Colour of the text where the pill covers it, the ink #15100c by default. Options: any CSS colour that reads on color; taken out of this block, --pill-nav-ink on the bar takes over.
   data-pill-nav-radius	100vmax	Corner radius of the pill, any CSS unit; a radius larger than half the pill is brought back to a full capsule.
   data-pill-nav-pad	0em	How far the pill reaches past the box of a link, any CSS unit, one value for the four sides or two, vertical then horizontal.
   data-pill-nav-stiffness	260	Pull of the spring that carries the leading edge of the pill.
   data-pill-nav-damping	22	Friction of the spring.
   data-pill-nav-stretch	0.5	How much softer the trailing edge is than the leading one, 0 to 1, and how much the pill thins while it is long.
   data-pill-nav-orientation	auto	Axis the pill stretches along. Options: auto reads it from each move, the longer way between the two links; horizontal and vertical hold it to one axis whatever the move.
   data-pill-nav-spy	0	Scroll spy: the link whose section is on screen becomes the current one while the page scrolls. Options: 0 off, the current link is the one marked in the markup or clicked; 1 on, for links to anchors of the same page.

Two files, no build step. It runs in the browser only. Load it with a script tag in plain HTML, in a client-side script in Astro, never in the frontmatter. In React, call PillNav.mount(ref.current) in useEffect and destroy() in its cleanup.

1. Tune it, either way

   Per element with an attribute, or once for the whole site by editing DEFAULTS at the top of the file.

   Attribute	Default	What it is	Lower	Higher
   data-pill-nav-color	#ffab1a	Colour of the pill, the amber #ffab1a by default. Options: any CSS colour; taken out of this block, --pill-nav-color on the bar takes over.
   data-pill-nav-ink	#15100c	Colour of the text where the pill covers it, the ink #15100c by default. Options: any CSS colour that reads on color; taken out of this block, --pill-nav-ink on the bar takes over.
   data-pill-nav-radius	100vmax	Corner radius of the pill, any CSS unit; a radius larger than half the pill is brought back to a full capsule.	Towards 0 a plain rectangle, a tab marker	A full capsule from half the height of a link on
   data-pill-nav-pad	0em	How far the pill reaches past the box of a link, any CSS unit, one value for the four sides or two, vertical then horizontal.	At 0 the pill is exactly the box of the link, right for links that carry their own padding	A pill wider than its link, for bare text links; 0.3em 0.8em suits most
   data-pill-nav-stiffness	260	Pull of the spring that carries the leading edge of the pill.	A slow, heavy pill that drags behind the pointer	A pill that snaps to the link, past 600 almost at once
   data-pill-nav-damping	22	Friction of the spring.	Under 14 the pill bounces several times before it rests	Past 32 no bounce at all, the pill glides in and the landing loses its squash
   data-pill-nav-stretch	0.5	How much softer the trailing edge is than the leading one, 0 to 1, and how much the pill thins while it is long.	At 0 a rigid pill that only slides	At 1 a long elastic drop that takes a moment to gather
   data-pill-nav-orientation	auto	Axis the pill stretches along. Options: auto reads it from each move, the longer way between the two links; horizontal and vertical hold it to one axis whatever the move.
   data-pill-nav-spy	0	Scroll spy: the link whose section is on screen becomes the current one while the page scrolls. Options: 0 off, the current link is the one marked in the markup or clicked; 1 on, for links to anchors of the same page.

2. Drive it from JavaScript

   When something other than the pointer should move the pill, when the current link changes from your own code, or when the page reacts to the link the pill is on.
   JavaScript Expand Copy

   const element = document.querySelector('[data-pill-nav]');
   element.addEventListener('pillnav:change', (e) => {
     console.log(e.detail);
   });

   const nav = PillNav.mount(element);   // the bar auto() mounted, or a new one
   nav.go(2);        // the pill travels to the third link, as under the pointer
   nav.leave();      // and comes back to the current link
   nav.select(1);    // the second link becomes the current one

   element.addEventListener('pillnav:change', (e) => {
     console.log('current link', e.detail.from, 'to', e.detail.index);
   });

   // When the bar leaves the page:
   PillNav.destroy(element);   // removes the pill, the copy and the listeners

   Show all 16 lines

3. Fit it to your page

   • Structure: one box marked data-pill-nav that holds the links, each marked data-pill-nav-link. The links need not be direct children: a list of li works. Without a single marked link, every a, button and [role="tab"] of the box is taken.
   • The current link is the one that carries aria-current, any value but false: aria-current="page" on a site of several pages, which Webflow writes by itself on a link to the page being shown. With no current link the pill is hidden at rest and shows under the pointer.
   • What the script adds: two boxes at the end of the bar. pill-nav-pill is the pill, laid over the links; pill-nav-over is a copy of the links in the ink colour, laid over the pill and clipped to its shape on every frame. Neither takes the pointer, the keyboard or a screen reader: the copy is inert and aria-hidden, its links are out of the tab order.
   • What the script writes: data-pill-nav-state on the bar, live while the pill travels, idle at rest, empty when there is no link to sit on; and aria-current on the links, moved to the link clicked or to the link the scroll spy reaches. The size and the place of the pill are inline styles on the pill itself, measured from the link, never on your elements.
   • A click makes the link current. The pill then comes back to it when the pointer leaves. On a site of several pages the page changes anyway; on tabs or anchors the bar keeps the choice.
   • One setting for every bar of the page, without opening the file: declare window.PillNavSettings = { color: '#d4ff3f', ink: '#15100c' } in a script placed before pill-nav.js. The three levels, least specific first, are DEFAULTS, then that object, then a data-pill-nav-* attribute on the bar itself (data-pill-nav-color="#d4ff3f"), so one bar can still differ from the page-wide setting.
   • The two colours can also come from the stylesheet: without a setting in the attributes or in the settings block, the custom properties --pill-nav-color and --pill-nav-ink on the bar are read, then DEFAULTS. The Embed writes its own copy of DEFAULTS into the settings block, so on a Webflow page the attribute is the way to change one bar.
   • A column of links needs nothing: with orientation on auto the pill stretches along the longer way between the two links, down a column and along a row, and a bar that turns into a column on a phone, as the preview's does at 767px, changes axis by itself.
   • Scroll spy, data-pill-nav-spy="1": every link whose href names an anchor of the page (#stock) watches that section, and the section that crosses a line 40% down the window becomes the current link, marked aria-current="location". A click holds the spy until the scroll it started has stopped, so the pill goes straight to the clicked link instead of visiting every section on the way.
   • **From JavaScript, beyond mount, auto and destroy**: the api carries element, settings, links(), current() and shown() (the index of the current link and of the link the pill is on, -1 for none), go(index) which sends the pill to a link as the pointer would, leave() which sends it back, select(index) which makes a link current as a click would, refresh() which reads the settings, the links and the sizes again, and frames() and isRunning() for a test that wants to see the loop sleep at rest. Two events bubble from the bar: pillnav:move when the pill takes another link, pillnav:change when the current link changes.
   • Links that change after load are followed without a call: a link added, removed, reworded, or given another class is seen by the script, which makes its copy again and puts the pill back.
   • **destroy() leaves the bar as it was**: the two boxes removed, the listeners and the observers gone, the state attribute taken off, and the inline position: relative removed if the script set it. aria-current stays where the last click put it: it is the page's state, not the effect's.
   • Touch: no hover on a finger, so nothing travels under it. A tap is a click: the tapped link becomes the current one and the pill travels to it with the same stretch.
   • **prefers-reduced-motion**: the pill jumps to its link, no travel and no spring, and it shows and goes without a fade. Turning the preference off brings the travel back without a reload.
   • The words of the markup are the preview's, and they ship as they are. Put the user's own words in their place whenever they want.
   • On Webflow, add the fonts first. Add Geist and Geist Mono to your site's fonts (Site settings, Fonts, Google Fonts) before pasting: the paste names them, and the Designer drops a font the site does not have.

4. Avoid the pitfalls

   • The pill is drawn over the links, not under them. That is what lets the covered text change colour without a blend mode: the pill hides the original text and the copy is drawn over it. A link's own hover background is therefore hidden where the pill is, and a link colour change on hover only shows outside the pill.
   • The script appends two boxes to the bar, so :last-child no longer matches the last link. Write :last-of-type, or put a class on the link. They are out of the flow: a flex or a grid bar does not count them as items, and they take no gap.
   • The copy is laid out like the bar. It takes the bar's padding and its flex or grid values, and clones every child. A bar laid out by something else, links placed one by one with absolute positions for instance, gives a copy that does not fall on the originals, and the covered text doubles.
   • **overflow: hidden on the bar clips the pill** when pad makes it reach past the bar's edge. A bar that scrolls sideways works: the pill is placed in the scrolled content and travels with it.
   • A transform that scales the bar breaks the measure: the boxes are read in screen pixels and written in the bar's own. Scale a parent of the bar's parent, or do not scale.
   • **Settings handed to mount() after the page loaded are dropped.** auto() mounts on DOM ready, and mount() on a bar that already carries the effect returns the existing one. A page-wide block goes in window.PillNavSettings, which auto() reads itself; a bar already mounted takes new attributes with refresh().
   • Scroll spy needs sections taller than a sliver. The line is 1% of the window tall; a section that never crosses it, the last one of a short page for instance, never becomes current by scrolling alone.

One click on Copy the AI prompt copies everything an assistant needs to build this effect: the complete code, the markup, the dependency, every setting and every pitfall.
